25-1414SC Tweeter 25mm TB Speaker TANG BAND
25-1414SC Tweeter 25mm TB Speaker TANG BAND
  • -15%
25-1414SC Tweeter 25mm TB Speaker TANG BAND
25-1414SC Tweeter 25mm TB Speaker TANG BAND

TANG BAND 25-1414SC Tweeter 25mm TB Speaker

SHIPMENT IN 5-7 WORKING DAYS
€38.25 €45.00 -15%
Tax included
rating No review at the moment

TANG BAND 25-1414SC  Tweeter 25mm TB Speaker

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



TANG BAND 25-1414SC  Tweeter 25mm TB Speaker

.

Brand TB-Speaker

Series Tweeter

Magnet Material Neodymium

Diaphragm Material Titanium

Diaphragm Diameter [mm] 25

Ferrofluid Yes

Free Air Resonance [Hz] 800

Impedance [Ohm] 4

Sensitivity [dB] 90

Power Handling [Watt] 8

Nominal impedance 4 Ω

Re 3 Ω

Sensitivity 1W / 1m 90 dB

fs 800 Hz

Voice coil diameter 25.4 mm

Nominal power 8 W

Maximum power 80 W

Bxl -

Mms -

Cms -

Sd -

Levc 0.008 mH

Zo 7 Ω

Xmax 0.28 mm

Vas -

Qts 0.78

Qms 1.89

Qes 1.34


25-1414SC
