CSS Torii MTM Speaker Kit 1 speaker

.

Product description CSS Torii MTM Speaker Kit

The CSS Torii MTM Speaker Kit is an affordable and high-quality entry point into the world of DIY high-end audio. Named after the traditional Japanese gateway, the Torii, this kit serves as a gateway into the CSS brand's offerings, providing exceptional audio performance at a competitive price.

.

Highlights of the CSS Torii MTM Speaker Kit

Uses CSS W5-06 woofers and T22-04 tweeters

SmartNode crossover boards for easy assembly

Sealed and ported flat pack options available

Designed for accurate and engaging sound reproduction

.

Product details CSS Torii MTM Speaker Kit

CSS Torii MTM Speaker Kit

The CSS Torii MTM Speaker Kit includes everything you need to build a pair of high-performance bookshelf speakers. The kit features CSS's W5-06 woofers and T22-04 tweeters, ensuring a balanced and detailed sound. The SmartNode crossover boards make assembly straightforward, even for beginners, by eliminating the need to read complex circuit diagrams.

The kit comes with an option for either sealed or ported flat packs, with CNC-rabbited edges for easy alignment during assembly. The sealed flat pack is 9 3/4" deep, while the ported version is 12" deep. The speakers' design has been fine-tuned through extensive measurements, modeling, and listening tests to ensure a musically engaging sound that competes with higher-end offerings.

Key specifications include: - Anechoic Response: ±3 dB from 50 Hz to 20 kHz - In Room Response: ±3 dB from 40 Hz to 20 kHz - F3: 50 Hz - Sensitivity: 86 dB - Impedance: 8 Ohm - Dimensions: 12” H x 7” W x 12” D

The CSS Torii MTM Speaker Kit is perfect for those looking to build their first high-fidelity speaker system or anyone interested in DIY audio projects. With a focus on ease of assembly and high-quality sound, it offers an excellent introduction to the CSS product line.
