Audaphon Cherlen 6 dB floorstanding loudspeaker from K+T magazine 5/2015

Kit without housing, price per speaker

The Cherlen 6 dB is a 2-way high-end bass reflex floor-standing loudspeaker with Air Motion Transformer. It uses the excellent Audaphon AMT 1i as a tweeter and the outstanding Morel TSCM 634 as a woofer. The separation is done with 1st order filters (6 dB per octave) to prevent the sound image from breaking up and to prevent the speakers from being able to be located with your eyes closed. If you want the speaker with a steep separation, Cherlen is also available with a 12/18 dB crossover. The crossover consists of a 1st order high pass (6 dB / octave) for the tweeter. A first order low pass (6 dB / octave) is used for the woofer. The frequency response of the speaker is very balanced. The decay spectrum is almost flawless. The nonlinear distortions at low volumes (85 dB, 1 m) are below 0.2% above 600 Hz and remain below 0.6% even at higher volumes (95 dB, 1 m).

Technical data:

• Impedance: 4 Ohm
• Sound pressure level (2.83V/1m): 86 dB
• Dimensions (HxWxD): 960 x 180 x 240 mm
• Frequency range (-8dB): 35 - 30000 Hz
• Crossover frequency(s): 2200 Hz
• Principle: bass reflex box

• Audaphon AMT-1i
• Morel TSCM 634
• 2x bass reflex tube HP70, 68x160 mm, black
• Insulating fleece MT Bondum 800 (30 x 50 x 2 cm)
• 0.5x PE foam sealing strip, 5x2 mm, roll 7.5 m
• Insulating material Sonofil 100 x 35 cm for 20 liters
• Pole terminals PK31, one pair, gold-plated, red+black
• 3m speaker cable 2x1.5 mm2, transparent
• Pan screws 4x20 black, 8 pieces
• Construction plan for the kit the crossover components (right), to be assembled on a wooden board.
• Audaphon MKP CAP Superior 6.8 μF / 400 Vdc
• Mundorf baked varnish air coil BL140, 0.68 mH/0.23 Ohm
• Metal oxide resistor MOX10 2.7 Ohm (red-violet-gold)
• Metal oxide resistor MOX10 4.7 Ohm (yellow-violet-gold)
