Audaphon Audimax Core floorstanding loudspeakers kit with high-end crossover
![rating](/modules/lgcomments//views/img/stars/square/yellow/0stars.png)
Audaphon Audimax Core floorstanding loudspeakers kit with high-end crossover
Kit with high-end crossover without housing, price per speaker
The high-end kit is equipped with baked varnish coils in the important places to reduce the microphonic effect. (The current through the coil generates a magnetic field, which in turn sets the winding in motion.
You might also like
Audaphon Audimax Core floorstanding loudspeakers kit with high-end crossover
Kit with high-end crossover without housing, price per speaker
.
The high-end kit is equipped with baked varnish coils in the important places to reduce the microphonic effect. (The current through the coil generates a magnetic field, which in turn sets the winding in motion. This movement induces voltages in the coil, which are added to the useful signal. The tighter the winding of the coil, the less the useful signal is distorted.) The capacitors for the tweeter - where quality is particularly important - are high-quality Mundorf Supreme Evo oil capacitors.
Technical data:
- impedance: 6 Ohm
- Sound pressure level (2.83V/1m): 86 dB
- Dimensions (HxWxD): 1200 x 250 x 350 mm
- Frequency range (-8dB): 26 - 40000 Hz
- Crossover frequency(s): 1650 Hz
- Principle: bass reflex box
Highlights
- Audaphon Ribbon NeoPro5i, aluminum, black, 1/2 pack
- 2x Hobby-HiFi woofer 18MW12T (produced by SEAS)
- JetSet 100AT, bass reflex system, outside
- JetSet 100IT, bass reflex system, inside
- 0.5x JetSet 100MR, bass reflex system, center
- JetSet 100WR (angled tube)
- Insulating fleece MT Bondum 800 (30 x 50 x 2 cm)
- 0.5x PE foam sealing strip, 5x2 mm, roll 7.5 m
- Insulating material Sonofil 100 x 35 cm for 20 liters
- Audaphon Damping 10, 970 x 470 mm, self-adhesive
- Pole terminals PK31, one pair, gold-plated, red+black
- 5m speaker cable 2x2.5 mm2, transparent
- 2.5x pan screws 4x20 black, 8 pieces
- Construction plan for the kit the crossover components (right), to be assembled on a wooden board.
- Mundorf MCAP EVO oil 0.47 μF / 450 V
- Mundorf MCAP EVO oil 1.5 μF / 450 V
- Mundorf MCAP EVO oil 4.7 μF / 450 V
- Mundorf MCAP EVO oil 10 μF / 450 V
- Mundorf Mcap Supreme EVO oil 4.7 μF / 800V
- Mundorf Mcap Supreme EVO oil 10 μF / 800V
- Mundorf HeptaLitze coil II45, 0.68 mH/0.34 Ohm
- Mundorf baked varnish air coil BL71, 0.18 mH/0.34 Ohm
- Mundorf baked varnish air coil BL71, 0.22 mH/0.34 Ohm
- Mundorf baked varnish air coil BL180, 2.2 mH/0.34 Ohm
- MResist Supreme resistor 6.8 Ohm / 20 Watt
- MResist Supreme resistor 8.2 Ohm / 20 Watt
- 2x metal oxide resistor MOX5 0.47 Ohm 5% (yellow-violet-silver)
- Metal oxide resistor MOX5 3.3 Ohm (orange-orange-gold)
.
.
