Audio System HLC-2 EM 2-way high-low adapter

.

2-way high-low adapter for OEM radios/amplifiers

.

Technical data

- Function: Prevents interference signals and switch-on noises

- Performance: HIGH POWER up to 100 WATT possible

- Features: Generates a switch-on signal (remote)

- Sound quality: Outstanding sound quality thanks to LOW-NOISE-AMPS (5 volts)

- Detection: Automatic BTL and music detection via PTC input

- Simulation: Speaker PRS load simulation (phantom resistor simulation)

- Size: 43x13x35 mm

- Accessories: Includes branch connector

.

Features

- Efficient suppression of interference signals and switch-on noises for a pure sound experience.

- Supports HIGH POWER applications up to 100 WATT, ideal for powerful audio setups.

- Automatically generates a switch-on signal (remote), simplifies installation and use.

- LOW-NOISE-AMPS ensure superior sound quality with up to 5 volts signal strength.

- Intelligent automatic detection of BTL configurations and music signals through the PTC input.

- PRS load simulation (Phantom Resistor Simulation) for optimized performance with speaker systems.

- Ultra-compact dimensions (43x13x35 mm) enable easy and flexible placement.

- Comes with branch connectors for quick and safe installation without additional tools.

.

The HLC 2 EM is a revolutionary solution for eliminating interference signals and switch-on noise in car audio systems. Designed to work with HIGH POWER applications of up to 100 WATT, this small but powerful adapter guarantees clean and undisturbed sound transmission. The use of LOW-NOISE AMPs with a signal strength of up to 5 volts ensures superior sound quality, while the integrated music and BTL detection via the PTC input enables automatic adjustment and optimal performance.

.

The innovative PRS load simulation (Phantom Resistor Simulation) optimizes the interaction with various speaker systems by simulating a realistic load and thus further improving the audio quality. With its ultra-compact size and the included branch connectors, the HLC 2 EM can be easily installed and accommodated in almost any vehicle.
