Volt Loudspeakers RV4564 18'' Radial Subwoofer 8 ohm

.

Product description

The Volt Loudspeakers RV4564 Radial Subwoofer is a powerful and highly reliable 18-inch subwoofer designed with advanced Radial Technology, ensuring optimal bass reproduction for professional studio monitors and high-end sub-bass systems.

.

Highlights

Radial chassis technology for superior cooling and heat dissipation

Triple cooling system: vented magnet, Radial chassis, and multi-finned magnet intercooler

High sensitivity of 93 dB/W/m

Wide frequency response range of 25 Hz to 500 Hz

.

Product details

The Volt RV4564 is engineered to deliver precise and powerful bass, making it ideal for high power professional studio monitors and sub-bass systems. This 18-inch driver utilizes Volt's Radial Technology, featuring a unique three-tiered cooling system: a vented magnet, the Radial chassis acting as a heatsink, and a multi-finned magnet intercooler. This design keeps voice coil temperatures exceptionally low, significantly reducing power compression and maintaining dynamic range even after prolonged operation at maximum power. The symmetrical field magnet system with an extended center pole allows for linear excursions up to 25mm peak-to-peak, ensuring accuracy and control.

.

Technical Specifications

Nominal Diameter: 450 mm (18 inches)

Power Handling: 750W RMS, 1500W Program Power

Sensitivity: 93 dB/W/m

Frequency Response: 25 Hz - 500 Hz

Impedance: 4 or 8 ohms

Voice Coil Diameter: 100 mm

Maximum Excursion: ±12.5 mm

Magnet Assembly Weight: 17 kg

Overall Diameter: 459 mm

Mounting Depth: 215 mm

Chassis: Diecast Aluminium

.

The Volt RV4564 Radial Subwoofer combines precision engineering with robust construction, providing reliable and high-fidelity audio performance, making it a top choice for audio professionals and enthusiasts seeking superior bass reproduction.
